GALAXY

LA+

Features

1. Machine width: The case of LA+ is smaller for save the more space, also save more space for container.
2.24 units of UD-16RLC+.
3.Canceled Machine foot.
4.Stand holder: Bigger and stronger.
5.. Emergency Stop position.

BRAND

GALAXY

MODEL

G23SN01
LA+ model

RIP SOFTWARE

Photoprint , Maintop

PRINT HEAD

I3200-E1

Printing Speed

I3200-E1 * 1

  • 2400 dpi Standard 3 Pass 34 sqm/H
  • 3600 dpi Quality 4 Pass 26 sqm/H
  • 4800 dpi H.Quality 6 Pass 17 sqm/H

INK TYPE

COLOR

C,M,Y,K

TYPE

Water-based ink
Eco-solvent ink Water-based ink

CAPACITY

5L per Main Tank of Each Color

INK SYSTEM

Eco-solvent ink

SPECIFICATION

PRINTING WIDTH

33.8

Length x Width x Height

69.1 x 59.4 x 35.6 (mm x mm x mm)

Weight

82 g

Number of nozzles

3200

Distance between nozzles (inch)

1/300(Same line)

Number of nozzle rows

8

Maximum number of ink colors supported

4

Resolution

300npi/single line
600npi/double line

Spray frequency

43.2(Single point)
21.6( Multi point)
