SMTJET SJ18S-3306

STARFIRE


Features

25*20*0.6CM Heavy-duty steel, more stable, high precision and strong pressure resistance
Wholly processed by professional high precision CNC milling machine, quality assurance.
Deformation resistance to pressure
Optional Independent take up system.

BRAND

SMTJET

MODEL

SJ18S-3306

RIP SOFTWARE

Maintop (Optional Photoprint, Onyx)

PRINT HEAD

STARFIRE 1024 10PL/25PL

Printing Speed

10 PL

4 HEADS

  • 2PASS 266qm/H
  • 3PASS 189sqm/H
  • 4PASS 147sqm/H

25 PL

6 HEADS

  • 2PASS 380sqm/H
  • 3PASS 270sqm/H
  • 4PASS 210sqm/H

INK TYPE

ECO SOLVENT INK / SOLVENT INK

SPECIFICATION


IMAGE FORMAT

TIFF/JPG/EPS/PDF

TAKE UP DEVICE

take up system (optional)

HEATING & DRYING

front and back heating, infrared drying

CONTROL SYSTEM

Win7/Win10 64 bit; CPU:I5 Above; Ram:4G Above; Port:USB2.0, USB3.0

POWER SUPPLY

AC220V,50H±10%,UPS is required

WORKING CONDITION

Temperature 0℃-40℃,Humidity60%-70%

G.W/N.W

1450kg/1200kg

PACKING SIZE

560*110*185CM

PRINTING MATERIALS

PP Paper, Vinyl Sheet, Film, Coated Paper, Banner, Canvas, Adhesive Vinyl Sheet, Banner

GALLERY
