TOSHIBA

TOSHIBA-CE4M

Features

1.Stable and strong machine body
2. Anti-collision
3. Individual vacuum area
4.Anti-static device
5.Double linear guide rail
6.Scratch-resistant printing platform
7.Double screw rod
8.Panasonic AC servo motor
9.Auto detect material thickness
10.LED UV Lamp with long life span
11.Computer and monitor can install into the printer as a unit for convenient operation
12.High quality imported UV curable ink

BRAND

GALAXY

MODEL

UD-25C8AJW
UD-25C8AJC

RIP SOFTWARE

Photoprint(Standrad)

PRINT HEAD

TOSHIBA CE4M

Printing Speed

UD-25C8AJW

6+2H

  • 6PASS 24sqm/H
  • 8PASS 20sqm/H
  • 12PASS 12sqm/H
  • 16PASS 10sqm/H

UD-25C8AJC

8H

  • 6PASS 48sqm/H
  • 8PASS 40sqm/H
  • 12PASS 24sqm/H
  • 16PASS 20sqm/H

INK TYPE

COLOR

C,M,Y,K,W
LC LM 2W
C,M,Y,K x2

TYPE

UV INK

CAPACITY

1L per Main Tank of Each Color

INK SUPPLY

Auto Ink Supply System

SPECIFICATION

Size

60x90cm
100x160cm
130x250cm
200x300cm

Maximum Printing Width

2500x1300mm

material Width

2500x1300mm

Media Type

PS Board, KT Board, PVC Foam Board, Acrylic, Aluminum, Glass, etc

Cleaning System

auto Cleaning System

Print Interface

USB 3.0

Printhead Height

1 to 100 mm from Media

Input Power

AC 220V/230V, 50Hz/60Hz

Print Power

4200W

Vacumm Power

1500W

Machine Dimension/N.W

L3871xW2165xH1190mm/825Kg

Package Dimension/G.W

L4350xW2210xH1680mm/1275Kg
